Monster Axles Front Right CV Axle for Can-Am ATV 705402236, XP Series

Location on vehicle: Front,Right

(0) Reviews: Write first review
CA-231XP
The Monster Axles™ XP Series axle is designed to be stronger, longer lasting, and more dependable, no matter where you ride.

Fits FRONT, RIGHT (passenger side) on the following Can-Am ATVs (excluding any XMR models) * 2019-2022 Outlander 650/Max 650 4x4 & 6x6, 2019-2022 Outlander 850/Max 850, 2019-2022 Outlander 1000/Max 1000 4x4 & 6x6, 2019-2022 Renegade 570/850, & 2019-2022 Renegade 1000.

A high-performance axle that can fit stock length all the way up to a 4" lift kit.

Key to its performance, the plunge mechanism is moved from the inner joint to the shaft itself, eliminating issues that cause joints to bind and break. Unlike other brands, our axle will not bind, burr, or mushroom, leaving you with a CV joint you can't remove from the shaft.

More angle, more plunge - With its inner CV joint designed like an outer joint, it can achieve a 45° angle of operation (OEM axles can only operate up to around 23°). The telescoping shaft provides 60 mm of travel (twice what you get from an OEM axle).

Serviceable in the field - Boots rip, it happens. Should you need to replace a broken joint or boot, the CV joint can be easily removed for service without any specials tools. No need to ship the whole axle back to us.

Built from a unique, stronger than OEM chromoly-forged steel axle shaft. Fitted with heavy duty boots for greater resistance to wear & punctures.

Contact us to inquire about replacement parts.

Shipping: Free Shipping - Same Day If Ordered Before 3 EST
Pricing: $179.95
Qty:
Free Ground Shipping

Application List

YearMakeModelSubmodelNotes
2022Can-AmOutlander 6504X4
2022Can-AmOutlander 6504X4 Mossy Oak Hunting Edition
2022Can-AmOutlander 6504x4 DPS
2022Can-AmOutlander 6504x4 XT DPS
2021Can-AmOutlander 6504X4
2021Can-AmOutlander 6504X4 Mossy Oak Hunting Edition
2021Can-AmOutlander 6504x4 DPS
2021Can-AmOutlander 6504x4 XT DPS
2020Can-AmOutlander 6504X4
2020Can-AmOutlander 6504X4 Mossy Oak Hunting Edition
2020Can-AmOutlander 6504x4 DPS
2020Can-AmOutlander 6504x4 XT DPS
2019Can-AmOutlander 6504X4
2019Can-AmOutlander 6504x4 DPS
2019Can-AmOutlander 6504x4 North Edition DPS
2019Can-AmOutlander 6504x4 XT DPS
2022Can-AmOutlander 8504X4
2022Can-AmOutlander 8504x4 DPS
2022Can-AmOutlander 8504x4 XT DPS
2022Can-AmOutlander 8504x4 XTP DPS
2021Can-AmOutlander 8504X4
2021Can-AmOutlander 8504x4 DPS
2021Can-AmOutlander 8504x4 North Edition DPS
2021Can-AmOutlander 8504x4 XT DPS
2021Can-AmOutlander 8504x4 XTP DPS
2020Can-AmOutlander 8504X4
2020Can-AmOutlander 8504x4 DPS
2020Can-AmOutlander 8504x4 North Edition DPS
2020Can-AmOutlander 8504x4 XT DPS
2020Can-AmOutlander 8504x4 XTP DPS
2019Can-AmOutlander 8504X4
2019Can-AmOutlander 8504x4 DPS
2019Can-AmOutlander 8504x4 North Edition DPS
2019Can-AmOutlander 8504x4 XT-P DPS
2019Can-AmOutlander 8504x4 XT DPS
2021Can-AmOutlander 1000R4x4 XT-P DPS
2021Can-AmOutlander 1000R4x4 XT DPS
2020Can-AmOutlander 1000R4x4 XT-P DPS
2020Can-AmOutlander 1000R4x4 XT DPS
2019Can-AmOutlander 1000R4x4 DPS
2019Can-AmOutlander 1000R4x4 Mossy Oak Hunting Edition DPS
2019Can-AmOutlander 1000R4x4 XT-P DPS
2019Can-AmOutlander 1000R4x4 XT DPS
2022Can-AmOutlander Max 6504x4 DPS
2022Can-AmOutlander Max 6504x4 XT DPS
2022Can-AmOutlander Max 6506x6 DPS
2021Can-AmOutlander Max 6504x4 DPS
2021Can-AmOutlander Max 6504x4 XT DPS
2021Can-AmOutlander Max 6506x6 DPS
2020Can-AmOutlander Max 6504x4 DPS
2020Can-AmOutlander Max 6504x4 XT DPS
2020Can-AmOutlander Max 6506x6 DPS
2019Can-AmOutlander Max 6504x4 DPS
2019Can-AmOutlander Max 6504x4 North Edition DPS
2019Can-AmOutlander Max 6504x4 XT DPS
2019Can-AmOutlander Max 6506x6 DPS
2022Can-AmOutlander Max 8504x4 XT DPS
2022Can-AmOutlander Max 8504x4 XTP DPS
2021Can-AmOutlander Max 8504x4 North Edition DPS
2021Can-AmOutlander Max 8504x4 XT DPS
2021Can-AmOutlander Max 8504x4 XTP DPS
2020Can-AmOutlander Max 8504x4 North Edition DPS
2020Can-AmOutlander Max 8504x4 XT DPS
2020Can-AmOutlander Max 8504x4 XTP DPS
2019Can-AmOutlander Max 8504x4 North Edition DPS
2019Can-AmOutlander Max 8504x4 XT DPS
2019Can-AmOutlander Max 8504x4 XTP DPS
2022Can-AmOutlander Max 10006x6 XT
2021Can-AmOutlander Max 10006x6 XT
2022Can-AmOutlander Max 1000R4x4 LTD DPS
2022Can-AmOutlander Max 1000R4x4 XT DPS
2022Can-AmOutlander Max 1000R4x4 XTP DPS
2021Can-AmOutlander Max 1000R4x4 LTD DPS
2021Can-AmOutlander Max 1000R4x4 XT DPS
2021Can-AmOutlander Max 1000R4x4 XTP DPS
2020Can-AmOutlander Max 1000R4x4 LTD DPS
2020Can-AmOutlander Max 1000R4x4 XT DPS
2020Can-AmOutlander Max 1000R4x4 XTP DPS
2020Can-AmOutlander Max 1000R6x6 XT
2019Can-AmOutlander Max 1000R4x4 LTD DPS
2019Can-AmOutlander Max 1000R4x4 XT DPS
2019Can-AmOutlander Max 1000R4x4 XTP DPS
2019Can-AmOutlander Max 1000R6x6 XT
2022Can-AmRenegade 5704X4
2021Can-AmRenegade 5704X4
2020Can-AmRenegade 5704X4
2019Can-AmRenegade 5704X4
2022Can-AmRenegade 8504X4
2022Can-AmRenegade 8504x4 XXC DPS
2021Can-AmRenegade 8504X4
2021Can-AmRenegade 8504x4 XXC DPS
2020Can-AmRenegade 8504X4
2020Can-AmRenegade 8504x4 XXC DPS
2019Can-AmRenegade 8504X4
2019Can-AmRenegade 8504x4 XXC DPS
2022Can-AmRenegade 1000R4x4 XXC DPS
2021Can-AmRenegade 1000R4x4 XXC DPS
2020Can-AmRenegade 1000R4x4 XXC DPS
2019Can-AmRenegade 1000R4X4
2019Can-AmRenegade 1000R4x4 XXC DPS

Product Notes

  • Fits FRONT, RIGHT (passenger side) on the following Can-Am ATVs (excluding XMR models): 2019-2022 Outlander 650/MAX 650 4x4 & 6x6, 2019-2022 Outlander 850/MAX 850, 2019-2022 Outlander 1000/MAX 1000 4x4 & 6x6, 2019-2022 Renegade 570/850, & 2019-2022 Renegade 1000.
  • The Monster Axles™ XP Series axle is designed to be stronger, longer lasting, and more dependable, no matter where you ride. A high-performance axle that can fit stock length all the way up to a 4" lift kit.
  • Key to its performance - The plunge mechanism is moved from the inner joint to the shaft itself, eliminating issues that cause most joints to bind and break. And should you need to replace a broken joint or boot, the CV joint can be easily removed for service without specialized tools.
  • More angle, more plunge - With its inner CV joint designed like an outer joint, it can achieve a 45 degree angle of operation (OEM axles can only operate up to around 23). Plus you have a telescoping shaft that provides and additional 60 mm of travel.
  • Replaces OEM # 705402236. Inboard CV joint spline count: 21, Outboard CV joint spline count: 26, Compressed overall axle length: 573 mm. Comes with a 1 year limited warranty (excluding torn boots).

    • What's In The Box

  • 1 axle

    • Warranty

    1 year, one-time repair/ replace. Buyer pays shipping

    Details

    • CA-231XP
    • CA-231XP
    • CUSTOM
    • MONSTER AXLES
    • Available
    • New

    Categories

    Shipping Information

    • Item Requires Shipping
    • 20.0 lbs.
    • W5.0000” x H5.0000” x L32.0000”
    • Free Ground Shipping
    • Free Shipping - Same Day If Ordered Before 3 EST
